High-Precision Powder Coating Booth with Cartridge Filters and Automated Reciprocator Application Systems
Our Powder Coating Booths with cartridge filter systems and integrated automatic powder coating gun reciprocators offer an efficient and cost-effective solution for high-quality coating operations. These systems are ideal for facilities that require high repeatability and minimal operator involvement, all while maintaining a clean and safe working environment.
In powder coating booths with cartridge recovery systems, powder particles suspended in the air are drawn in by the suction fan and captured by high-efficiency cartridge filters. One of the key advantages of this system is its low investment cost and ease of maintenance. Powder particles do not crumble in this system, and the quality of the reused paint is not deteriorated.
The cartridge filters are cleaned automatically via an electronic pulse system controlled by a built-in circuit board, while manual filter cleaning buttons are also available on the control panel. Air is drawn through the cartridge filter area in the booth, allowing overspray particles to be effectively collected.
A powder collection depot with a sieve is located at the base of the booth. Overspray falling onto the sieve is automatically recycled: the collected powder is sent back to the guns via injectors, enabling efficient paint reuse and reducing waste.
With automated reciprocators / robotic systems, powder application becomes uniform and highly repeatable, even across complex part geometries. The system supports programmable settings and full synchronization between the application equipment and booth functions, maximizing productivity and finish quality.
Customizaton to Fit Your Needs:
Elsisan’s Powder Coating Booths with Cartridge Filter and Automated Reciprocator Application Systems are fully customizable to match your specific needs, from heating elements to material and process requirements. We can design a solution that meets your exact specifications.
